Splice

4f Ribbon Splicing

0.05dB
11 Sec.

Fibre Protection

Single Automatic
Oven

30Sec.
40mm single sleeve

Battery

100 Splice

BU-12L
Li-ion 11.1V 3060mAh
Power monitor

Display &
Operation

3.5" LCD
Touch screen

Shock
resistance

Drop from 76cm
on the Bottom Face

Water & Dust
Resistance

IP51 Equivalent

Dust test;
8 hours in a
test chamber with
circulating dust
particles smaller
than 75um

Water test;
Exposed to vertically
dripping water at
1mm/min. for 10 min.

Storage

Internal:
200 images
10000 data

Internal + External
(SD/SDHD):
50200 images
20000 data

Help Video

Play on the display
or our web site

Automation

Splice/Oven auto start

Network
Connection

FSMA:
via PC by USB

Electrode Life

3000 splices

Operating
Condition

Temperature :
-10 ~ +50 ℃

Humidity :
0 ~ 95%
(non-condensing)

Altitude :
0 ~ 3660m,
Wind velocity :
up to 15m/sec

Storage
Condition

Splicer body
Temperature :
-40 ~ +80 ℃
Humidity : 0 ~ 95%
(non-condensing)

Battery
Temperature :
-20 ~ +30 ℃
(long term storage)
