• Increase productivity optical access networks field personnel
• Intuitive and responsive
• One-button measurement
• Trace and map view

• Fast and precise
• The time domain reflectometer offers great safety
• Resistant to hard working conditions

• AQ2200-112 Light source module
• High output level stability performance
• AQ2200 Multi-Application Test System

High Stability reference laser light sources for DWDM channel measurements. The one or two channel modules are part of an integrated optical device testing solution for the AQ2200 series frame controller platform.

The AQ2200-212 is single channel sensor module with an analog output port.

Ideal for measuring output power of transmission equipment and optical fiber amplifiers.

Increase your testing power and capability with the AQ2200-222 sensor module.

• AQ2200-232 Optical Sensor Head (Large diameter detector, 800 to 1700 nm)
• AQ2200-242 Optical Sensor Head (Large diameter detector, 400 to 1100 nm)
• AQ2200-202 Interface Module (2-channels)
• High performance optical sensor heads and interface module

• AQ2200-312 Optical Attenuator module
• Small, lightweight variable optical attenuator providing low insertion loss
• SM, GI50, and GI62.5 fiber optic attenuator types available

With built-in optical power meter for monitoring power
Compact and lightweight optical variable attenuator.
SM, GI50 and GI62.5 optical fiber models available.

• Superior switching reproducibility
• Compact optical switches
• SM, GI50 and GI62.5 optical fiber models available

"Hot-swapping" capability and remote monitoring and control are even easier with Ethernet support.

• Multi application test system
• Two frame controller platforms
• Select best platform size for intended measurement applications

A 12-channel optical switch box that effectively improves workability with YOKOGAWA OTDRs.

The AQ6150B measures the wavelength and power levels of both CW and Modulated optical signals from transceivers and WDM transmission systems.

• Wavelength range: 900 to 1700 nm
• Wavelength accuracy: ±0.7 ppm

• Wavelength and power level of CW and modulated optical signals from tunable lasers and DWDM transmission systems
• Range: 900 to 1700 nm
• Accuracy: ±0.2 ppm

• Cost-effective optical spectrum analyzer
• Diffraction grating technology
• Ideal for optical device manufacturing

• Popular TELECOM wavelength Range of 600nm to1700nm
• New model ideal for Telecommunications applications for single-mode and multi-mode optics

• The high-performance optical spectrum analyzer optimized for visible laser measurement
• 3 models line up for various applications [Standard, High resolution, Limited]
• Ideal for the lasers of industrial, bio and medical

• Wide range optical spectrum analyzer covering from visible light to communications wavelength
• Wide wavelength range: 350 to 1750 nm
• Ideal for various applications including fiber
