GS200 DC Voltage / Current Source Pulse Generator_

Voltage source up to ±32 V and current source up to ±200 mA; 5½-digit, 120,000-count output resolution; optional simple voltage/current monitor function; programmable output up to 10,000 points; built-in USB storage device; channel expansion via synchronous operation. Description: The most stable and accurate device for the most sensitive and demanding applications. The GS200 is Yokogawa's premier mid-range source measure unit. It combines accuracy, ease of use, and limitless functionality: Limitless applications — from traditional semiconductor characterization to quantum computing; four-quadrant sourcing and sinking; generation of pulse-width modulation, ramp, step, and arbitrary waveforms. Ease of use — can be used as a storage device or integrated into an automated test system; upload/download setup files, test patterns, and results with the press of a button; requires no programming or software development. Uncompromising accuracy — extremely low-noise voltage and current generation capabilities; multi-unit synchronization to increase voltage or current without sacrificing accuracy or resolution. Video: no video available on the product page. Product image: https://cdn.tmi.yokogawa.com/1/282/files/GS200-Front-M.png GS820/GS610/GS200 High Accurate Voltage/Current Source and Measurement Unit — https://cdn.tmi.yokogawa.com/LF7656-30E.pdfhttps://cdn.tmi.yokogawa.com/1/6218/files/IMGS210-01EN.pdf
